Remplace aussi le 75H05

Ref : LM323K Moderne
Prix unitaire .
Photo non contractuelle .

• Clean turn on and turn off.
• Drop-in replacement of the obsolete LM323K and LM78H05K  or equivalent linear voltage regulator.
• Guaranteed 3A continuous output current.
• Identical input voltage range of 7.2V to 20V
• Suitable for use in Pinball machines and video game consoles
• High efficiency switching regulator design reduces power dissipation with superior voltage regulation compared to the LM323K.
• Thermal shutdown and current limit protection
• Board dimensions are identical to the TO3 package of the LM323K.
• Heatsinks are optional.
• All components are mounted on one side of the PCB
• Highest component is the inductor at 5mm above the PCB.
• Sold with pins soldered in place.
• Gold plated pins and PCB to withstand harsh environments over the long term.
• Can drive inductive loads such as solenoids and DC motors.
• 500kHz Switching Frequency
• Made in the USA
