Eprom de mise a jour CPU pour flipper Road Show ( Roadshow )

Rev : L6

Ref : EC03730

Changes from revision L-5:

    Fixed XX bonus display.

    Fixed display bug in New Orleans mode.  It was displaying the
    incorrect score value for the next shot.

    Fixed a bug in Super Payday where the wrong city and score was
    awarded.  This bug only showed up on multi-player games.

    Added adjustment for the shaker motor (default=NORMAL)
    Values are NORMAL, SOFT, and OFF

    Added adjustment to allow buyins once a player has reached
    the West Coast (default=OFF).

    Fixed blinking lamp in blast zone from 2x Atlanta blast.  The
    lamp was being left on.

    Fixed ALL TARGETS SCORE 16,xxx,xxx display bug in Super Payday
    introduction screen.

    Added jackpot compensation for broken Red mouth switch.

    Multiball restart timer is now paused while ball is in the lockup.
    (e.g. for Extra    Ball display effect)

    Enhanced the handling of the proximity switches in front of Ted
    and Red.  They are now better debounced in case they are
    intermittent.

    Added special code to limit the amount of time the Red and Ted
    eyelids are activated to prevent the coils from overheating.


U6:    Version L-5
    LA-5 Checksum: 2405
    LX-5 Checksum: F105
    Date: December 15, 1994

Changes from revision L-4:

    Fixed a few French translations.

    Changed Special and Replay % for France.  Turned on Match
    for France.

    With TOURNAMENT set to YES, the souvenirs are awarded
    in order instead of randomly.

    Shut "Red" up when the wheel isn't lit on a bridge-out.

    Fixed the Spinner value.  It was not ever being initialized,
    so that it would carry over from ball to ball and
    game to game.

    Fixed a small display glitch in the Nashville award.

    Fixed a TILT problem with Flying Rocks. It was possible
    to restart start Flying Rocks after a TILT.

    Changed to only 1 replay level for Germany.

    Accumulated bonus credit fractions are cleared at the
    end of ball, unless coins have been inserted recently.

    After 9 minutes of idle time, any credit fractions less
    than 1/2 are cleared.


U6:    Version L-4
    LA-4 Checksum: 6804
    LX-4 Checksum: 9904
    Date: October 26, 1994

Changes from revision L-3:

    Fixed the adjustment STARTING DAY.  If it was set to anything
    but MONDAY, it would score and make a sound at game start.

    Fixed the Special award.  It was awarding a special from either
    lane if either lamp was lit.

    Changed default BALL SAVE TIME to ON.

    Added 26 score levels to the spinner scoring so that it
    doesn't MAX as fast.

    If LONGER PATH was set to OFF, there was a possibility
    of the first city being Atlanta.  It has been fixed to
    allow only New York City or Miami.

    Put in French translations.

    Fixed up some effects.

    Changed it so you can now go to MIAMI from the west coast.

    Put SPAIN 2 and coin meter into Spanish preset.

    Fixed a problem with Super Payday.  It was sometimes fetching
    an incorrect award and displaying "HOULTON 0,000,000".

    Fixed display and speech in Atlanta. If the player aborted
    the instructions and quickly made the blast zone shot, the
    display would behave incorrectly.


U6:    Version L-3
    LA-3 Checksum: 0B03
    LX-3 Checksum: D903
    Date: October 12, 1994

Changes from revision L-2:

         Added the last of the German translations.  This also fixes
         2 phrases which were too long to fit on the screen in
         the Albuquerque effect.

         Fixed a bug where sometimes the "select a souvenir"
         computer noise was not getting killed.


U6:    Version L-2
    LA-2 Checksum: BC02
    LX-2 Checksum: B202
    Date: October 10, 1994

Changes from revision L-1:

         Fixed a serious bug in the exploding font effect.  When
         jumpered for Germany, which causes periods to be exploded,
         some games would crash.


U6:    Version L-1
    LA-1 Checksum: BA01
    LX-1 Checksum: B001
    Date: October 7, 1994



Ref : EC 03700

Prix unitaire

Photo non contractuelle
